B-EYE har revolutioneret måden, vi opfatter LED-belysning til shows og events på. Den innovative optiske enhed forbedrer både ensartetheden og effektiviteten af lysudbyttet. Den roterende frontlinse og muligheden for individuel styring af hver enkelt LED har gjort det muligt at skabe spektakulære kalejdoskopiske projektioner og imponerende eye-candy-effekter. En avanceret effektmotor gør det lettere at anvende makroeffekter i det daglige arbejde, som ellers ville være vanskelige at programmere. Disse teknologiske innovationer gør B-EYE til et yderst alsidigt armatur: en højtydende LED wash, en perfekt beam og en spektakulær projektor til visuelle effekter – alt samlet i ét armatur. B-EYE har modtaget adskillige priser og er gennem årene blevet kopieret af utallige producenter.
I dag tilbyder Claypaky HY B-EYE, som er dobbelt så kraftig og leverer et væsentligt højere lysudbytte end B-EYE. Den tilbyder samtidig endnu større alsidighed og forbedret interaktion med mediaservere (inklusive Kling-Net-protokollen). Samtidig arbejder den meget støjsvagt, mens den bevarer samme størrelse og styringsplatform som B-EYE.
Specifikationer
Detaljer
- LIGHT SOURCE:
- Source type:
- RGBW LEDs
- Power:
- 40W (x19)
- Color Temperature:
- 6000 K.
- LED life expectancy:
- 50000 hrs.
- It may vary depending on various factors, such as the type of use and environment
- PHOTOMETRIC DATA:
- Zoom Range:
- 4°-60°
- Lumen output:
- 13.500Lm (integrating shere)
- Optical System:
- Pateted 19 lens system
- NOISE LEVEL:
- Fixed pressets:
- Standard - Auto: 43.8
- Standard - Full: 46.2
- Quiet - Auto: 43.6
- Quiet - Full: 46.3
- Theatre - Auto: 42.4
- Theatre - Full: 46.3
- CONTROL and CONNECTIONS:
- Personalities:
- Basic Engine: 21/22/35/36
- Pixel engine: 57/76
- Protocols:
- DMX, Art Net, sACN, RDM
- Connectors:
- Locking 3 / 5 pin XLR IN/ OUT
- RJ45 IN
- Power connector:
- PowerCon True1 IN/OUT
- Web server:
- Built in
- CloudIO:
- Fully compatible
- On field calibration for color consistency
- DYNAMIC EFFECTS:
- Colors:
- Built in macros with enhanced pixel control
- Preset colors
- Dedicated channel for color temperature setting
- White CT Emulation 2500 8000K
- RGBW auto tuning to lamp CT Emulation
- Tungsten Lamp Emulation
- Rotating effect:
- Bi directional rotating front lenses
- Movement:
- Tilt: 200°
- Pan: 540°
- Automatic repositioning
- Mechanical Pan/Tilt lock for safe transportation and maintenance
- Beam:
- Motorized zoom
- Dimmer/Shutter:
- High resolution electronic dimmer 24 bit, 4 curves
- High speed electronic shutter and strobe:
- Slow strobe: 1 flash/sec
- Fast strobe: 25 flash/sec
- HARDWARE and SOFTWARE:
- Long life self-charging battery
- Display Graphic LCD backlit B/W Display
- Firmware upload from another fixture
- Firmware Upgrade via Web Server
- Diagnostic
- DMX monitoring
- Remote access through RDM
- HOUSING:
- Aluminium and steel structure with plastic covers
- Two side handles for transportation
- IP20 protection rate
- Working in any position
- Hanging system: with fast lock Omega clamps (1/4) turn on the base
- Optional safety chain
- ELECTRICAL:
- Working in any position.
- Hanging system: with fast-lock omega clamps (1/4 turn) on the base.
- Optional safety chain.
- ELECTRICAL
- Optical voltage: 100 240V, 50/60 Hz
- Power Supply: Electronic auto range with active PFC
- MAX power consumption: 700 VA @230 Vac 50 Hz
- THERMAL SPECIFICATION
- Max ambient temperature: 40°C (104°F)
- Max temperature of the external surface: 90°C (194°F)
- Total heat dissipation: 2597 BTU/hr ±10% / 2736 kJ/hr ±10%
- SAFETY SPECS
- Min. distance of illum. objs: 0.2 m ( 8’’)
- Min. dist. from flamm. mat.: 0.2 m ( 8’’)
- Protections:
- Thermally protected power supply (overheating and cooling)
- Forced ventilation with axial fans
- COMPLIANCE
- CE Marking (in conformity to the following)
- 2014/35/EU Safety of electrical equipment supplied at low voltage ( LVD)
- 2014/ 30/EU Electromagnetic compatibility (EMC)
- 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
- 2009/125/EC EcoDesign requirements for Energy related Products (ErP)
- UKCA conforms to UK regulations:
- S.I. 20 16 N. 1101
- S.I. 2016 N. 1091
- S.I. 2012 N. 3032
- S.I. 20 10 N. 2617
- cETLus LISTED:
- UL 1573:2003
- CSA C22.2 N.166:2015
- PACKAGING
- Carton box + Polystyrene
- Carton box + Foam shell
- Flight case + Foam shell (4 positions)
- WEIGHT - SIZE
- Weight: 20.7 Kg (45.6 lbs)
- Base dims: 329 x 387 mm 12.95 x 15.24 In
- Height with horiz head (h): 496 mm 19.53 In
- Dist. b/t 2 fixt: 600 mm
- ACCESSORIES
- Omega bracket: 2x183102-805 (Included)
- ETL Power: CAB03D-802 (Included)
- Cord 1.5 m (bare end with IP65 PowerConTrue1 conn.)
- Flight case (4 pos): CF1002F (Optional)
- Foam shell: F21314-001 (Optional)
- Safety Chain: 105041-003 (Optional)
- Clamp: C21070 (Optional)
