Specifikationer
Detaljer
- LIGHT SOURCE:
- Source type:
- RGBW LEDs
- Power:
- 40W (x37)
- Color Temperature:
- 6000 K.
- LED life expectancy:
- 50000 hrs.
- It may vary depending on various factors, such as the type of use and environment
- PHOTOMETRIC DATA:
- Zoom Range:
- 4°-60°
- Lumen output:
- 16.100Lm (integrating sphere)
- Optical System:
- Patented 37 lens system
- NOISE LEVEL:
- Fixture: HY B Eye K25:
- Fixed preset:
- Auto mode standard: 46.5 dB
- Auto mode quiet: 47.0 dB
- Stationary: 33.5 dB
- Fixture: HY B Eye K25 Teatro:
- Fixed presets:
- Auto mode super silent: 35.0 dB
- Auto mode silent 36.0 dB
- Auto mode standard: 39.0 dB
- CONTROL and CONNECTIONS:
- Personalities:
- Basic Engine: 21/22/35/36
- Pixel engine: 111/148
- Protocols:
- DMX , Art Net, sACN, RDM
- Connectors:
- Locking 3 / 5 pin XLR IN/ OUT
- RJ45 IN
- Power connector:
- PowerCon True1 IN/OUT
- Web server:
- Built in
- CloudIO:
- Fully compatible
- On field calibration for color consistency
- DYNAMIC EFFECTS:
- Colors:
- Built in macros with enhanced pixel control
- Preset colors
- Dedicated channel for color temperature setting
- White CT Emulation 2500 8000K
- RGBW auto tuning to lamp CT Emulation
- Tungsten Lamp Emulation
- Rotating effect:
- Bi directional rotating front lenses
- Movement:
- Tilt: 210°
- Pan: 540°
- Automatic repositioning
- Mechanical Pan/Tilt lock for safe transportation and maintenance
- Beam:
- Motorized zoom
- Dimmer/Shutter:
- High resolution electronic dimmer 24 bit, 4 curves
- High speed electronic shutter and strobe:
- Slow strobe: 1 flash/sec
- Fast strobe: 25 flash/sec
- HARDWARE and SOFTWARE:
- Long life self-charging battery
- Display Graphic LCD backlit B/W Display
- Firmware upload from another fixture
- Firmware Upgrade via Web Server
- Diagnostic
- DMX monitoring
- Remote access through RDM
- HOUSING:
- Aluminium and steel structure with plastic covers
- Two side handles for transportation
- IP20 protection rate
- Working in any position
- Hanging system: with fast lock Omega clamps (1/4) turn on the base
- Optional safety chain
- ELECTRICAL:
- Working in any position.
- Hanging system: with fast-lock omega clamps (1/4 turn) on the base.
- Optional safety chain.
- ELECTRICAL:
- Optical voltage: 100 240V, 50/60 Hz
- Power Supply: Electronic auto range with active PFC
- MAX power consumption: 1250 VA @230 Vac 50 Hz
- THERMAL SPECIFICATION:
- Max ambient temperature: 40°C (113°F)
- Max temperature of the external surface: 90°C (194°F)
- Total heat dissipation:5329 BTU/hr ±10% / 5616 kJ/hr ±10%
- SAFETY SPECIFICATIONS:
- Min. distance of illum. objs: 0.2 m ( 8’’)
- Min. dist. from flamm. mat.: 0.2 m ( 8’’)
- Protections:
- Thermally protected power supply (overheating and cooling)
- Forced ventilation with axial fans
- COMPLIANCE:
- CE Marking (in conformity to the following)
- 2014/35/EU Safety of electrical equipment supplied at low voltage ( LVD)
- 2014/30/EU Electromagnetic compatibility (EMC)
- 2011/65/EU Restriction of the use of certain hazardous substances (RoHS)
- 2009/125/EC EcoDesign requirements for Energy related Products (ErP)
- UKCA conforms to UK regulations:
- S.I. 20 16 N. 1101
- S.I. 2016 N. 1091
- S.I. 2012 N. 3032
- S.I. 20 10 N. 2617
- cETLus LISTED:
- UL 1573:2003
- CSA C22.2 N.166:2015
- PACKAGING
- Carton box + Polystyrene
- Carton box + Foam shell
- Flight case + Foam shell (2 positions)
- WEIGHT - SIZE
- Weight: 27.5 Kg ( 60.6 lbs)
- Base dims: 329 x 387 mm 12.95 x 15.24 In
- Height with horiz head (h):590 mm 23.23 In
- Dist. b/t 2 fixt: 600 mm
- ACCESSORIES
- Omega bracket: 2x183102-805 (Included)
- ETL Power: CAB03D-802 (Included)
- Cord 1.5 m (bare end with IP65 PowerConTrue1 conn.)
- Flight case (4 pos): CF1001F (Optional)
- Foam shell:F21313-001 (Optional)
- Safety Chain: 105041-003 (Optional)
- Clamp: C21070 (Optional)
